WDL-CDJ-5000 Immersion Electric Melting Furnace with 5000 kg Capacity and 70 kW Heating Power for Precise ±2°C Temperature Control

WDL-CDJ-5000 Immersion Electric Melting & Holding Furnace – Vertical Insertion Type for Aluminum Alloy Die Casting

The WDL-CDJ-5000 Immersion Electric Melting and Holding Furnace (Vertical Insertion Type) from WUXI WONDERY INDUSTRY EQUIPMENT CO., LTD. is a high-efficiency, energy-saving solution designed for non-ferrous metal solution holding, particularly aluminum alloy in die-casting foundries.

Unlike traditional radiant heating furnaces, this immersion furnace heats the molten aluminum directly from the inside. This unique design delivers thermal efficiency over 30% higher than conventional systems, significantly reducing energy consumption while maintaining stable performance. The direct heating method also minimizes oxide production and ensures precise temperature control with an accuracy of ±2°C during the holding stage.

Key advantages of the WDL-CDJ-5000 include low energy costs, compact footprint, easy operation with intermittent shutdown capability, and convenient heating element replacement after basic on-site training. The patented furnace structure extends service life, while all exposed parts are fitted with protective covers to ensure operator safety.

The furnace is equipped with a Siemens PLC control system, touchscreen interface, and Keyence laser liquid level detection. An external LED digital display allows operators to remotely monitor real-time molten aluminum temperature. The furnace body and cover are built with multi-layer insulation materials including calcium silicate boards, ceramic fiberboards, and nano insulation boards from Japan and Sweden, keeping external temperature rise below 20°C above ambient.

With a rated capacity of 5000 kg of aluminum liquid, heating power of 70 kW, and maximum power consumption of 75 kW, this furnace is ideal for high-demand die-casting processes. It operates on 415VAC/50Hz three-phase five-wire power, and includes a degassing device at the soup inlet for improved melt quality.

For more technical specifications or a customized quotation, please contact WUXI WONDERY INDUSTRY EQUIPMENT CO., LTD. today.

Technical Parameters Table:
