70KW Medium Frequency Induction Industrail Metal Melting Furnace for Steel Copper Aluminum Gold
1.Advantages
The tilting type gold industrial metal melting furnace is tilting type.
This type metal induction furnace has a small size, a light weight and
is very convenient in use. The tilting method can be mechanical tilting,
hydraulic tilting, or electrical tilting type. According to the customer’s requirement,
the infrared thermometer and the temperature controller can be added additionally.
2.Features
2.1 The tilting type induction melting furnace has a small and compact structure.
It is very easy in installation and operation.
2.2 The industrial metal melting furnace has a fast melting speed and saves energy consumption.
2.3 We have full range electric metal melting furnace and induction
heat treatment furnaces. The frequency can be low frequency, medium frequency or high frequency.
2.4 The induction industrial metal melting furnace adopts IGBT power device and unique frequency
conversion technology to operate stably and provide higher reliability and durability.
2.5 The induction melting furnace has alarm function and fault detection function, such as
fault state protection and display including overcurrent, overvoltage and water shortage, etc.
3.Technical Parameters of 70KW MF Induction Industrial Metal Melting Furnace
| Working Power | 70KW |
| Input voltage range | 70V-550V |
| Output oscillation frequency | 1-20KHZ |
| Output current | 20-130A |
| Weight |
Main machine: 60kg; Control cabinet: 55kg |
| Dimension |
Furnace: 940*650*1100mm(L*W*H); Power supply: 700*350*620mm(L*W*H); Control cabinet: 550*400*510mm (L*W*H) |
| Cooling type | Water cooling |
| Cooling water requirement |
≥0.3Mpa ≥20L/min |
| Melting capacity of common materials | 100KG copper/brass/red copper 100kg gold, 100kg silver, 25kg steel, 25kg aluminum |
| Graphite crucible size (mm) | Outer diameter / total height: 315*410mm |
