70KW Medium Frequency Aluminum Gold Electric Steel Induction Copper Melting Furnace

70KW Medium Frequency Aluminum Gold Electric Steel Induction Copper Melting Furnace

Brand Name:	WONDERY
Model Number:	WDL-70KW
MOQ:	1SET
Price:	TO BE NEGOTIATED
Delivery Time:	3-5 WORKING DAYS
Payment Terms:	L/C, D/P, T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Name of equipment:

Industrial Metal Melting Furnace

Principle:

Induction Melting

Cooling Water:

20L/min

Weight:

About 150kg

Power:

70KW

Input Voltage:

70V-550V

Packaging Details:

PALLET

Supply Ability:

1000 SETS PER MONTH

Highlight:

70KW induction copper melting furnace wondery

550V induction copper melting furnace

20L/min electric steel melting furnace

Product Description

70KW Medium Frequency Induction Industrail Metal Melting Furnace for Steel Copper Aluminum Gold

1.Advantages

The tilting type gold industrial metal melting furnace is tilting type.

This type metal induction furnace has a small size, a light weight and

is very convenient in use. The tilting method can be mechanical tilting,

hydraulic tilting, or electrical tilting type. According to the customer’s requirement,

the infrared thermometer and the temperature controller can be added additionally.

2.Features

2.1 The tilting type induction melting furnace has a small and compact structure.

It is very easy in installation and operation.

2.2 The industrial metal melting furnace has a fast melting speed and saves energy consumption.

2.3 We have full range electric metal melting furnace and induction

heat treatment furnaces. The frequency can be low frequency, medium frequency or high frequency.

2.4 The induction industrial metal melting furnace adopts IGBT power device and unique frequency

conversion technology to operate stably and provide higher reliability and durability.

2.5 The induction melting furnace has alarm function and fault detection function, such as

fault state protection and display including overcurrent, overvoltage and water shortage, etc.

3.Technical Parameters of 70KW MF Induction Industrial Metal Melting Furnace

Working Power	70KW
Input voltage range	70V-550V
Output oscillation frequency	1-20KHZ
Output current	20-130A
Weight	Main machine: 60kg; Control cabinet: 55kg
Dimension	Furnace: 9406501100mm(LWH); Power supply: 700350620mm(LWH); Control cabinet: 550400510mm (LWH)
Cooling type	Water cooling
Cooling water requirement	≥0.3Mpa ≥20L/min
Melting capacity of common materials	100KG copper/brass/red copper 100kg gold, 100kg silver, 25kg steel, 25kg aluminum
Graphite crucible size (mm)	Outer diameter / total height: 315*410mm
