Heat Treatment Furnace
Created with Pixso. Automatic Heat Treatment Furnace Sealed Box Resistance For Gears Bearings

Automatic Heat Treatment Furnace Sealed Box Resistance For Gears Bearings

Brand Name: WONDERY
Model Number: RX
MOQ: 1SET
Price: TO BE NEGOTIATED
Delivery Time: 3-5 WORKING DAYS
Payment Terms: L/C, D/P, T/T, Western Union
Detail Information
Place of Origin:
CHINA
Certification:
CE
Name of equipment:
Heat Treatment Furnace
Capacity:
300-1360kg/h
Furnace type:
Sealed Box Type
Type:
Fuel Gas
Application:
Carburizing And Quenching
Customized service:
Yes
Rated temperature:
950 Degree Celcius
Voltage:
170 3 Phase 50HZ
Packaging Details:
STANDARD PACKAGE SUITABLE FOR SEA TRANSPORTATION
Supply Ability:
1000 SETS PER MONTH
Highlight:

Automatic Heat Treatment Furnace

,

Sealed Box Resistance Heat Treatment Furnace

,

Heat Treatment Furnace For Gears Bearings

Product Description

Sealed Box Type Resistance Furnace Automatic Heat Treatment Furnace For Gears Bearings



1.Introduction:

The production line absorbs the advantages of the similar foreign

furnaces and has been widely used in the China market.

The production line is equipped with a computer management system.



2. Application:

The heat treatment furnace is widely used for carburizing and quenching of

gears, bearings, shafts and other mechanical parts.

Features: Fast carburizing, thick case depth, stable quality.







3. Main Specifications and Parameters



Model Rated power (kw) Rated temperature

Working size

(mm)

Production

Capacity (kg/h)

RX-1 50 950 610*760*610 300-400
RX-2 75 950 610*920*610 400-600
RX -3 100 950 760*920*760 600-800
RX-4 120 950 760*1220*760 800-1000
RX-5 170 950 960*1220*760 1000-1360



4. Our Company Introduction

Wondery is an enterprise focusing on the planning, design, production and after-sales

service of mesh belt heat treatment furnaces.

We have support roller type electric resistance and gas fired mesh belt furnace,

stainless steel solutioning mesh belt furnace, pipe annealing mesh belt furnace, etc.





Mesh Belt Heat Treatment Furnace Supplied by Wondery:

Automatic Heat Treatment Furnace Sealed Box Resistance For Gears Bearings 0
