Industrial Aluminum Melting Furnace
Created with Pixso. High-Efficiency Baghouse Dust Collector System | Aluminum Melting & Casting Fume Control

High-Efficiency Baghouse Dust Collector System | Aluminum Melting & Casting Fume Control

Brand Name: WONDERY
Model Number: High-Efficiency Baghouse Dust Collector System
MOQ: 1SET
Price: TO BE NEGOTIATED
Delivery Time: 35 WORKING DAYS
Payment Terms: L/C, D/P, T/T, Western Union
Detail Information
Place of Origin:
CHINA
Certification:
CE
Dust Removal Efficiency:
> 99%
Heating Method:
Direct Heating Of The Outer Cylinder
Type:
Bright Flame Burner
System:
Proportional Combustion
Application:
Aluminum Melting For Casting And Alloy Production
Furnace:
Graphite Crucible
Packaging Details:
PLYWOOD CASE PACKAGE
Supply Ability:
1000 SETS PER YEAR
Highlight:

industrial aluminum melting furnace dust collector

,

baghouse dust collector for aluminum casting

,

high-efficiency fume control system

Product Description

High-Efficiency Baghouse Dust Collector System | Aluminum Melting & Casting Fume Control

WUXI WONDERY INDUSTRY EQUIPMENT CO., LTD. presents its advanced Baghouse Dust Collector System, a tailored industrial air pollution control solution specifically engineered for the aluminum scrap melting, casting, and aluminum ash recycling industry. This comprehensive system is designed to effectively capture and filter smoke, dust, and particulate matter generated during critical processes such as furnace charging, stirring, refining, slagging, and hot aluminum slag separation, ensuring full compliance with stringent national and international environmental regulations.

Our dust collection system employs a sophisticated yet robust process flow: flue gas and fugitive emissions are first directed through a settling chamber to remove larger particles, then enter the core baghouse filter for fine particulate removal. The cleaned air is finally expelled via an induced draft fan and chimney. The system is designed for maximum operational flexibility and energy efficiency, featuring an intelligent airflow control system linked to furnace door status. This smart regulation automatically adjusts the exhaust volume based on real-time production needs, significantly reducing energy consumption during non-peak operations without compromising capture efficiency.

Key to the system's performance is the high-quality baghouse design, utilizing side-intake airflow for uniform distribution and pre-dust removal, coupled with a reliable pulse-jet cleaning mechanism featuring "soft-landing" valves to extend filter bag life. The entire system is constructed from durable materials, including Q235-B steel with corrosion protection, ensuring long-term reliability in demanding industrial environments.

Core Technical Parameters of the Baghouse Dust Collector System:



Parameter Specification / Design Value
Processing Air Volume 70,000 m³/h (Max Design)
Inlet Dust Concentration ≤ 10 g/Nm³
Outlet Emission Concentration ≤ 30 mg/Nm³ (Measured under operating conditions)
Dust Removal Efficiency > 99%
Filtration Method Offline Pulse-Jet Cleaning
Filter Bag Material Polyester Needle Felt
Filter Bag Dimensions Ø135 mm x 6000 mm
Number of Filter Bags 512
Total Filtration Area 1302 m²
System Resistance ≤ 1200 Pa
Main Fan Power 110 kW (with frequency converter for energy saving)

This Dust Collector System from WUXI WONDERY INDUSTRY EQUIPMENT CO., LTD. is more than just pollution control; it's a strategic investment for sustainable and responsible production. It helps aluminum recyclers and smelters meet environmental compliance (like GB31574-2015), improve workplace safety and hygiene, recover valuable particulates, and reduce operational costs through intelligent energy management. As a part of our complete aluminum recycling line solutions, this system guarantees reliable performance, helping your business achieve both environmental goals and production efficiency.
