Electrical Heating Tunnel Oven For Continuous Heat - Treatment Processes

Name: Electrical Heating Tunnel Oven For Continuous Heat - Treatment Processes
Brand: Wuxi Wondery Industry Equipment Co., Ltd
SKU: WDL-CXLSD300
Availability: InStock

Brand Name:	WONDERY
Model Number:	WDL-CXLSD300
MOQ:	1 Set/Sets
Price:	TO BE ENGOTIATED
Delivery Time:	60 days
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Jiangsu,China(Mainland)

Certification:

Heating Speed:

RT~60℃ Less Than 20 Minutes

Chain Plate Effective Length:

3000*900 (length*width Mm)

Input Power:

12KW

Temperature Uniformity:

±2.5℃(tested At Constant Temperature Without Load)

Temperature Range:

RT (room Temperature) ~ 100℃ Adjustable

Studio Size:

2000*950*300 (depth*width*height Mm)

Packaging Details:

wooden case suitable for sea transportataion or nude package

Supply Ability:

200 Set/Sets per Year

Highlight:

Electrical Heating Tunnel Oven

Continuous Heat Treatment Tunnel Oven

Product Description

Electrical Heating Tunnel Oven For Continuous Heat - Treatment Processes

Product introduction: Equipment number: 20171108

Model: WDL-CXLSD300

Working temperature range: RT (room temperature) ~ 100℃ adjustable

Temperature uniformity: ±2.5℃％ (tested at constant temperature without load)

Heating speed: RT~60℃ less than 20 minutes

Air transport mode: Double duct horizontal circulation air transport, good temperature uniformity.

Internal effective dimensions: 2000*950*300 (depth*width*height mm)

Chain plate effective length: 3000*900 (length*width mm)

Internal material: stainless steel

Internal structure: Speed regulating stainless steel chain plate

Power supply: 380V/50HZ (3 phases + neutral wire + ground wire)

Input power: 12KW

Protection device: over-temperature protection, leakage protection, grounding protection

After-sales service commitment: one-year warranty and maintenance for the whole machine.

The above products can be customized in various non-standard sizes according to customer needs!

Product Introduction: Equipment No.: 2013-1-12

Model: CXLSD-7001

Working temperature range: RT (room temperature) ~ 180℃ adjustable

Temperature uniformity: ±2.5℃％ (tested at constant temperature without load)

Heating speed: RT~100℃ less than 20 minutes

Air transport mode: Double duct horizontal circulation air transport, good temperature uniformity.

Internal effective dimensions: 6000*800*350 (depth*width*height mm)

Chain plate effective length: 7000*800 (length*width mm)

Internal material: stainless steel

Internal structure: Speed regulating stainless steel chain plate

Power supply: 380V/50HZ (3 phases + neutral wire + ground wire)

Input power: 27KW

Protection device: over-temperature protection, leakage protection, grounding protection

After-sales service commitment: one-year warranty and maintenance for the whole machine.

The above products can be customized in various non-standard sizes according to customer needs!
