Industrial Aluminum Melting Furnace for Clean and Contamination Free Alloy Liquid Production

Industrial Aluminum Melting Furnace for Clean and Contamination-Free Alloy Liquid Production

1. Operation principle of Aluminum alloy dosing & holding furnace

WDL pneumatic dosing furnace is designed to take metal below the surface of

the metal liquid in the bath, which can avoid completely the oxidization slug and

tremendously imp rove the quality of the alloy liquid.WDL pneumatic dosing

furnace is designed to feed directly and automatically to the diecasting machine

or gravity mold free of any contamination.In order to feed the alloy liquid,

overpressure is formed inside the furnace chamber .The level of alloy liquid

inside the rising tube is raised first until the alloy liquid is about to overflow. When

the diecasting machine request the alloy liquid, the pressure inside the furnace

chamber will be increased further in order for the alloy liquid to flow out. The

pressure will be decreased to end the dosing once preset amount being reached.

After dosing completed, the liquid level is raised back to the feeding level for the

next dosing.

2. Technical Requirements

• Work voltage three phase and five line :3 ∅AC380V±10%, 50Hz/60Hz;
• Work environment:- 10℃~+50℃
• Compressing air driness dew point: -45℃
• Air pressure: 0.4~0.8Mpa
• Compressed air in let connector: DN25
• Compressed air instant volume(work pressure fluctuation range≤0.15Mpa)≥30-40L/S

3.Operation principle of Aluminum alloy dosing & holding furnace

WDL pneumatic dosing furnace is designed to take metal below the surface of the metal liquid

in the bath, which can avoid completely the oxidization slug and tremendously imp rove the

quality of the alloy liquid.WDL pneumatic dosing furnace is designed to feed directly and

automatically to the diecasting machine or gravity mold free of any contamination.In order

to feed the alloy liquid, overpressure is formed inside the furnace chamber .The level of alloy

liquid inside the rising tube is raised first until the alloy liquid is about to overflow. When the

diecasting machine request the alloy liquid, the pressure inside the furnace chamber will be

increased further in order for the alloy liquid to flow out. The pressure will be decreased to end

the dosing once preset amount being reached.After dosing completed, the liquid level is raised

back to the feeding level for the next dosing.

4. Features

• Chamber whole body casting
• Holding bath closed seal
• Silicon Carbide Rod Radiation Heating
• Pneumatic dosing feeding system, Holding furnace direct feeding
• Based on feeding position hydraulic rising function of the furnace
• Hydraulic dumping function for furnace chamber changing and cleaning
