1.1 The industrial aluminum melting and holding furnace is used along
with the die-casting machine, and it has a high efficiency, and a low labor strength.
1.2 The industrial aluminum melting furnace has the features of low metal
melting loss rate. Metal burn loss is lower than 1.5%.
1.3 The aluminum metal melting furnace has the advantages of flexible
applications, suitable for various sites.
1.4 The industrial aluminum liquid temperature control accuracy is at ±5℃.
1.5 The industrial metal melting furnace works with a variety of fuels such
as natural gas, LPG, and diesel.
1.6 The lining service life of the aluminum melting furnace is greater than 5 years.
1.7The control system of the aluminum alloy melting furnace adopts Mitsubishi
PLC programmable controller, which can operate safely and reliably.
| Model | Melting Capacity (kg/h) |
Holding capacity (kg) |
Burner capacity | Overall Size mm | Liquid Outlet Size (mm) | |||
| Melting burner kcal/h |
Holding burner kcal/h |
High | Long | Wide | ||||
| WDL-RBL-100 | 100 | 350 | 8×104 | 8×104 | 2200 | 2900 | 1550 | 320×350 |
| WDL -RBL-150 | 150 | 500 | 12×104 | 12×104 | 2300 | 3100 | 1650 | 350×420 |
| WDL -RBL-200 | 200 | 650 | 15×104 | 12×104 | 2500 | 3250 | 1750 | 400×450 |
| WDL-RBL-250 | 250 | 800 | 20×104 | 15×104 | 2600 | 3450 | 1750 | 450×500 |
| WDL -RBL-300 | 300 | 950 | 20×104 | 15×104 | 2800 | 3600 | 1800 | 500×550 |
| WDL -RBL-400 | 400 | 1200 | 25×104 | 20×104 | 2800 | 3880 | 1880 | 550×600 |
| WDL -RBL-500 | 500 | 1500 | 30×104 | 20×104 | 3000 | 3980 | 1950 | 500×550 |
| WDL -RBL-750 | 750 | 2000 | (15×2)×104 | 25×104 | 3300 | 4180 | 1980 | 550×600 |
The continuous aluminum melting furnace is suitable for woring beside the die casting machine.
The aluminum melting furnace
is comprised of melting chamber and holding chamber. The industrial metal melting furnace can
be added with online degassing function.
