Isothermal Spheroidizing Mesh Belt Furnace Push Rod Electric Annealing Furnace

1SET
MOQ
TO BE NEGOTIATED
Price
Isothermal Spheroidizing Mesh Belt Furnace Push Rod Electric Annealing Furnace
Features Gallery Product Description Request A Quote
Features
Specifications
Name of equipment: Mesh Belt Furnace
Capacity: 180-1000kg/h
Furnace type: Push-rod Type
Type: Electric Resistance
Application: Isothermal Spheroidizing Annealing
Customized service: Yes
Rated temperature: 820 Degree Celcius
Voltage: 500 3 Phase 50HZ
Highlight:

Isothermal Mesh Belt Furnace

,

Spheroidizing Mesh Belt Furnace

,

Push Rod roller hearth furnace

Basic Infomation
Place of Origin: CHINA
Brand Name: WONDERY
Certification: CE
Model Number: DWQH
Payment & Shipping Terms
Packaging Details: STANDARD PACKAGE SUITABLE FOR SEA TRANSPORTATION
Delivery Time: 3-5 WORKING DAYS
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 1000 SETS PER MONTH
Product Description

Push-rod Isothermal Spheroidizing Annealing Heat Treatment Furnace



1. Application

The push rod isothermal spheroidizing annealing heat treatment furnace is applicable to

isothermal annealing of bearing inner and outer ferrule, and forged parts.

2. Features

The push rod isothermal spheroidizing heat treatment furnace has a high energy efficiency,

and a low power consumption rate.



3. Company Features

Our company has more than 30 years in manufacturing heat treatment furnaces. We have full

range of heat treatment products such as mesh belt furnace, push rod isothermal spheroidizing

annealing heat treatment furnace, pit type wire annealing furnace,pit type carburizing furnace, stainless

steel vessel stress removing heat treatment furnace, etc. The energy of the heat treatment furnace can

be gas or electricity. We could guide our customer about the  heat treatment process too.





4. Main Specifications and Parameters



Model Rated power (kw) Rated temperature

Overall dimension

(mm)

Trays

Production

Capacity (kg/24h)

Total length(mm)
DWQH-1 120 820 640*560*65 16 180~200 10500
DWQH-2 160 820 640*560*65 20 250~300 12800
DWQH-3 200 820 640*560*65 24 450~500 15600
DWQH-4 350 820 1000*800*65 17 650~750 19000
DWQH-5 500 820 1200*1000*65 18 900~1000 22000





We are a professional supplier of mesh belt furnace. We have also gas fired mesh belt furnace

for tempering, annealing, quenching, carburizing treatment.
